| Place of Origin: | China |
|---|---|
| Brand Name: | OEM/ODM |
| Certification: | CE, RoHS |
| Minimum Order Quantity: | 10 pcs |
| Price: | sales@sogootech.com |
| Packaging Details: | PP bag+ paper carton |
| Delivery Time: | 3-20 days depends on quantity |
| Payment Terms: | Paypal,T/T, Western union |
| Supply Ability: | 100000 pcs per week |
| Product Name: | MPO Outdoor Waterproof Fiber Cable | Key Words: | MPO Waterproof Fiber Cable |
|---|---|---|---|
| Connector: | MPO LC Connector | Application: | RRU Installation |
| Cores: | 8 16 24 Cores | Waterproor: | IP67 |
| High Light: | MPO outdoor Fiber cable,MPO outdoor waterproof Fiber cable,MPO waterproof Fiber cable |
||
Application
1. Multi-purpose Outdoor.
2.For connection between distribution box and RRH. 3.Deployment in Remote Radio Head cell tower applications.
1.Cost effective solution for in house termination. 2.Low insertion loss and added loss.
3. Height of attenuation.
4. Water proof, dust proof and corrosion resistant
5.The material in the jumpel cable are all-weather and UV-resistant. 6.IP68 water and dust protection.
6.Mechanical performance: IEC 61754-7 standard. 8.RoHS and REACH materials compliant.
| Type | Reference | Note | |
|
MPO |
IEC 61754-7 |
Single mode |
APC: Black connectors APC: Black connectors |
| Multimode | PC: Black Connectors | ||
|
MTP |
IEC 61754-7 |
Single mode |
APC: Black connectors APC: Black connectors |
| Multimode | PC: Black Connectors | ||
Dimensional Diagrams
1. Mini IP MPO Outdoor Cable Assemblies
| Jumper tolerance requirement | |
| Overall length (L) (M) | length of tolerance(CM) |
| 0<L≤20 | +10/-0 |
| 20<L≤40 | +15/-0 |
| L>40 | +0.5%L/-0 |
Cable Structure
Cable Parameters
|
Cable Count |
Out sheath Diameter (MM) |
Weight (KG) |
Minimum allowable Tensile Strength (N) |
minimum allowable Crush Load (N/100mm) |
Minimum Bending Radius (MM) |
Storage temperature (℃) |
|||
| short term | long term | short term | long term | short term | long term | ||||
| 8/12/24 | 5.0±0.3 | 32 | 500 | 250 | 750 | 300 | 20D | 10D | -20 ~~ +70 |
Cable Parameters
|
Cable Count |
Out sheath Diameter (MM) |
Weight (KG) |
Minimum allowable Tensile Strength (N) |
minimum allowable Crush Load (N/100mm) |
Minimum Bending Radius (MM) |
Storage temperature (℃) |
|||
| short term | long term | short term | long term | short term | long term | ||||
| 8/12/24 | 5.0±0.3 | 32 | 500 | 250 | 750 | 300 | 20D | 10D | -20 ~~ +70 |
