Huawei ETP48200-B2A1 Embedded Power Switching System With 48V30A R4830G1 Module Outdoor Communication 5G

Basic Information
Place of Origin: China
Brand Name: Huawei
Certification: UL, RoHS
Model Number: ETP48200-B2A1
Minimum Order Quantity: 10 pcs
Price: 70~100 USD/pc
Packaging Details: Carton
Delivery Time: 5-8 working days.
Payment Terms: T/T
Supply Ability: 1000pcs
Product Name: Huawei ETP48200-B2A1 Power Switching System INPUT: 100~240v: 50/60Hz
Power Module: 48V30A R4830G1 Module Application: Huawei ETP48200-B2A1 Power Module
High Light:

Huawei ETP48200-B2A1 Power Switching System

,

Huawei Power Switching System 48V200A

,

Huawei Power Switching System 48V200A

Huawei ETP48200-B2A1 Embedded Power Switching System

Huawei ETP48200-B2A1 is a Embedded Power Switching System With 48V30A R4830G1 Module. ETP48200-B2A1 embedded DC power supply system, realize AC input conversion to stable 48 V DC output, support 2 kW rectifier module, maximum output power 10 kW.



Each functional unit adopts standardized size design, supports hot plug, system height 2 U, supports standard 19 inch rack or embedded cabinet and other installation methods. The system can adapt to wide range of AC input, with intelligent battery management, remote monitoring and other functions.



Characteristics:



Applications:

Parameters:

Product

Type

ETP48200-B2A1







Syst em

Dimensions (width × depth × height) ×255 mm ×86.1 mm)
Weight ≤10 kg( no rectifier module)
Temperature Control Mode Natural heat dissipation
Installation mode Installation of 19 inch rack or embedded cabinet
Routeing Move forward
Maintenance mode Pre-maintenance
Protection level IP20





AC

Distribution

Input format

220/380 V AC three phase, compatible with 220 V AC single phase,

110V AC Double Fire Line

HVDC( HVDC)
Input voltage 85~300 V AC, rated voltage :220 V AC 100V DC ~420 V DC, rated voltage: 200~380 V DC
Frequency 45~66 Hz, rated frequency :50/60 Hz /
Input empty open -
AC output -





DC

Distribution

Output voltage Voltage rating ~42~58 V DC,:53.5 V DC
Maximum capacity kW 10
Battery empty ×100 A/1P
Load down ×80 A/1P,4×63 A/1P,2×40 A/1P
Battery down -





Rectifier module

Type R4815G1 R4830G1
Rated power 1000W (176~300 V AC) 2000W (176~300 V AC)
Dimensions (width × depth × height) 95.5 mm ×208 mm ×40.8 mm
Efficiency

>95%(25% to 100%With load)

>98%Maximum

>95%(25% to 100%With load)

>96%Maximum



Monitoring module

Type SMU11C SMU11B
Communications ports RS485(Huawei master-slave agreement) FE (SNMP protocol)



Envi ronmen t

Working temperature

-40℃~+65℃

(When used at 2000~4000 m altitude, the maximum operating temperature is

reduced by 1℃ per 200 m rise)

Storage temperature -40℃~+70℃
Relative humidity 5%~95%(no condensation)
Height ~4000 m



Huawei ETP48200-B2A1 Embedded Power Switching System With 48V30A R4830G1 Module Outdoor Communication 5G 0Huawei ETP48200-B2A1 Embedded Power Switching System With 48V30A R4830G1 Module Outdoor Communication 5G 1Huawei ETP48200-B2A1 Embedded Power Switching System With 48V30A R4830G1 Module Outdoor Communication 5G 2Huawei ETP48200-B2A1 Embedded Power Switching System With 48V30A R4830G1 Module Outdoor Communication 5G 3Huawei ETP48200-B2A1 Embedded Power Switching System With 48V30A R4830G1 Module Outdoor Communication 5G 4Huawei ETP48200-B2A1 Embedded Power Switching System With 48V30A R4830G1 Module Outdoor Communication 5G 5





Packing&Shipping
Lead time:
We have a lot of stock ,If the quantity isn't very big , we can send the goods as soon as possible after recieve payment.If big quanity, the lead time need according to the quantity.

Transporting:
If small quantity, usually send by courier (DHL,FEDEX,TNT and so on) . If big quantity, we advice ship by air or by sea. this will use longer time ,but cheaper fees. We are near the port of TianJin.

Our service:
We can offer the sample. If the quality is good, we can offer very very competitive price .And can pack according to customer's requirment.

FAQ

1. How about the quality?

A: Many of our company's products are sourceed from well-known manufacturers, and the quality is absolutely in line with the corresponding international standards. Some of our company's products are project surplus purchased from telecommunications operators. We guarantee that the products are the original package.



2. Could i buy 1pc sample first and small order ?
A: Of course, support sample order and small order, especially for new customers under certain condition.



3. How much for 1pc sample ?
A: We can provide free sample for some products, but customers need to bear the shipping cost. For some products, we charge a corresponding sample fee.



4. If i have my thoughts, do you have person to design according to my concept?
> Certainly,our R&D team is willing to help you.



5. How long to make a sample?
> 3days which depends on the samples' complexity.
