12 Awg Dia Bare Copper Ground Wire Cable 16mm2 10mm2 Green Yellow Color

Basic Information
Place of Origin: Guangdong, China
Brand Name: SOGOO
Certification: CE, RoHS
Minimum Order Quantity: 1000m
Packaging Details: 10pcs in 1 Anti-static package, standard packing
Delivery Time: 7-10 working days
Payment Terms: T/T; Paypal; Western Union
Supply Ability: 2000 pcs per week
Contact Now

16mm2 10mm2 12 awg bare copper aluminum galvanized steel green yellow ground wire cable

Application Of Copper PVC Earth Grounding Wire Cable Green/Yellow

1. The PVC coated copper earth cables is designed to be used as a conductor in grounding and lightning protection systems.

2. Earth Cables are the most important component of any grounded or structural lightning protection system.

3. PVC coated copper earth cables are used for electrical transmission and distribution, grounding and lightning protection for generators and electronic applications.

4. The PVC coated copper earth cables are mainly used as a conductor for the lightning protection system of the building structure.

5. This green/yellow earth cables can be matched to the most common building materials to provide an aesthetically pleasing appearance to the external lightning protection system.

6. PVC sheathing materials are UV resistant, but some discoloration may occur over time.

7. Copper is annealed and easy to use.

Characteristics:

Operating temperature: +5°C to +70°C on the Conductor
Rated voltage: H05V-K: 300/500 V
H07V-K: 450/750 V
Max. temperature of short circuit: 160° C on the conductor
140° C on the conductor / size>300 mm2
Min. bending radius: Fixed installation: 4x outer diameter



Specifications Data:

Section Max diam. of conductor Insulation
thickness*
Outer
diameter
Max resistance
at 20°C
Cable
weight
mm² mm mm mm ohms/km kg/km
H05V-K
0,5 0,21 0,6 2,1 39,0 9
0,75 0,21 0,6 2,3 26,0 12
1 0,21 0,6 2,5 19,5 15
H07V-K
1,5 0,26 0,7 2,9 13,3 20
2,5 0,26 0,8 3,6 7,98 30
4 0,31 0,8 4,1 4,95 45
6 0,31 0,8 4,7 3,30 65
10 0,41 1,0 6,1 1,91 110
16 0,41 1,0 7,1 1,21 160
25 0,41 1,2 8,7 0,780 250
35 0,41 1,2 9,9 0,554 340
50 0,41 1,4 11,6 0,386 480
70 0,51 1,4 13,3 0,272 670
95 0,51 1,6 15,2 0,206 890
120 0,51 1,6 17,0 0,161 1140
150 0,51 1,8 18,9 0,129 1410
185 0,51 2,0 21,0 0,106 1710
240 0,51 2,2 23,9 0,0801 2270



Look forward to your inquiry on 16mm2 10mm2 12 awg bare copper green yellow ground wire cable.
