Anti Rodent Armoured Outdoor Fiber Optic Cable

Basic Information
Place of Origin: Guangdong
Brand Name: SOGOO
Model Number: GYTA33
Minimum Order Quantity: 50 pcs
Price: Negotiable
Packaging Details: Export Carton Packing
Delivery Time: 3-20 days depends on quantity
Payment Terms: T/T, Western Union
Supply Ability: 100000m per week
Product Name: GYXTW Armored Direct Burial Cable 12 Core Fiber Optic Cable Price Per Meter Key Words: Armored Direct Burial Fiber Cable
Fiber: 12/24/48/72/96/144/288 Core Material Of Jacket: Black Polyethylene (PE)
Storage / Operating Temperature: -40℃~+70℃ Application: Outdoor Duct And Conduit Installation
High Light:

Anti Rodent Fiber Optic Cable

,

Armoured Fiber Optic Cable

,

Armored Fiber Optic Cable

GYTA33 (G652D) direct bury outdoor anti rodent Armoured Fiber Optical Cable

GYTA33 cable is an outdoor communication optical cable of metallic strength member of the loose tube jelly-filled structure, with Al-polyethylene laminated sheath and single-layer thin round steel wire armored polyethylene outer sheath.

The loose tubes are made of high modulus plastics (PBT) and filled withwater resistant filling gel. Loose tubes are stranded around the metallic central strength member, cable core is filled with cable filling compound.The corrugated aluminum tape is longitudinally applied over the cable core,and combined with polyethylene (PE) inner sheath. Galvanized steel wires are stranded around inner sheath, and then extruded with PE outer sheath.



Feature



Performance

Fiber Count Nominal Diameter (mm) Nominal Weight (kg/km) Max Fibers per Tube No. of (Tubes+fillers) Allowable Tensile Load (N) Allowable Crush Resistance (N/100mm)
Short Term Long Term Short Term Long Term
2~30 15.5 407 6 5 10000 4000 5000 3000
32~36 16.0 437 6 6 10000 4000 5000 3000
38~60 16.6 463 12 5 10000 4000 5000 3000
62~72 17.2 499 12 6 10000 4000 5000 3000
>72 Available upon customer’s request

Note:

1. According to different applications, GYTA333, GYTS33, GYTS333, GYTY53+33, GYTY53+333, GYTA53+33, GYTA53+333 can provided.

2. Special cable structure can be designed and manufactured on customer’s request.

Anti Rodent Armoured Outdoor Fiber Optic Cable 0Anti Rodent Armoured Outdoor Fiber Optic Cable 1Anti Rodent Armoured Outdoor Fiber Optic Cable 2

Anti Rodent Armoured Outdoor Fiber Optic Cable 3

Recommend Products

Anti Rodent Armoured Outdoor Fiber Optic Cable 4

Anti Rodent Armoured Outdoor Fiber Optic Cable 5

Packaging and Shipment

Anti Rodent Armoured Outdoor Fiber Optic Cable 6

Contact us

Anti Rodent Armoured Outdoor Fiber Optic Cable 7

Look forward to your inquiry on our GYTA33 (G652D) direct bury outdoor anti rodent Armoured Fiber Optical Cable.
